Product Details:
|
| Product Name: | EV Portable Charger | Work For: | Electric Vehicle |
|---|---|---|---|
| Terminal: | Copper Alloy+ Silver Plating | Plug Type: | IEC62196 |
| Certification: | CE,TUV | Connection: | Plug In |
| IP Protection: | IP54 | Power: | 3.5kw |
| Cable Length: | 5M / Customizable | Warranty: | 1 Year |
| Charging Plug: | Schuko Charging Plug | Working Temperature: | -30℃- +50℃ |
| High Light: | IEC62196 Plug In EV Portable Charger,3.5kw EV Portable Charger 1 Phase |
||
This IEC62196 Standard electric vehicle charger is very easy to use, portable, and safe.
Enclosure material is thermoplastic, flame retardant grade UL94 V-0, the cable Material is
TPU. the terminals material is Copper alloy, silver plating.
Description of EV Portable Charger:
1.1 Phase 16A 3.5KW Adjustable
2. IEC62196 Standard
3. Schuko charging plug
| Specifications | Product Name | EV Portable Charger |
| Charging Plug | Schuko charging plug | |
| Rated Current | 1 Phase 16A adjustable | |
| Power | 3.5kw | |
| Working temperature | -30~50℃ | |
| Material | Enclosure | Thermoplastic, flame retardant grade UL94 V-0 |
| Cable Material | TPU | |
| Terminals/Pins | Copper alloy, silver plating | |
| Safety and warranty | Certification | CE,TUV |
| Certification Standard | IEC62196 Standard | |
| Protection Level | IP54 | |
| Warranty | 1 year | |
| Product parameter | Dimension | 34cm*34cm*10.5cm |
| Weight | 2.5kg |
Hunan Llano Electronic Technology Co., Ltd.
Our company is founded by a group of specialists who have been engaged in autogas
products since 2002. Our products cover a diversity of various models of ECUs, change-over
switches, emulators, MAP sensors, timing advance processors, injector rails, reducers, EV
portable charger and etc..
RAQ:
Q: How to use ev charger?
A: You need to connect the ev charger to the power supply and then insert the charging plug
into your car. If you have selected the RFID card, it will only start charging after you have
swiped the RFID card. app version you can control the start or stop of charging on your mobile
phone, and you can also make appointments to charge at certain times.
Q: what's the MOQ?
A: If you are ordering just one product, we can also customise the logo or change the colour of
the panel for you, but these customisations are available at an additional cost. Please contact
us for more information.
Q: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and
fixtures.
CAUTION:
1. Power-supply side input cable should be at least 3*2.5 mm recommended 3*4 mm), with a
standard 16A socket. It is suggested that the power distribution is done by the professionals.
2. Don't put your fingers into the charging connector when the power plug is still connected
to the power.
3. Don't use this EV charging box when the cable is damaged.
4. Don't step on, fold, or knot the cable.
5. Don't drop the EV charging boxor place a heavy object on it.
