Product Details:
|
Product Name: | CNG Pressure Gauges | Work For: | CNG Cars |
---|---|---|---|
Inspective Pressure: | 0~400 Bar | Material: | Stainless Steel And Brass |
Color: | Black | Quality: | 100% Professional Test |
Certificate: | ISO 9001 | Warranty: | 1 Year |
Highlight: | Electronic Sensor CNG Pressure Gauges,Autogas Switch CNG Pressure Gauges,Electronic Sensor cng digital meter |
CNG pressure gauge is installed on the CNG reducer to measure the CNG gas pressure
which indicates the amount of remaining CNG fuel in the CNG cylinder of a autogas conversion
system. It is integrated with a gas pressure sensor which can transmit the measurements to
the indicator type PETROL-CNG change-over switch to display by indicator lights.
Nominal diameter | 50 mm |
Accuracy grade | 2.5 |
Output signal | ± 0.25 V |
Installation type | Radial, axial |
Material | Cover: stainless steel; Joint: brass |
Joint thread |
G1 / 4 (Pf1 / 4), M14 × 1.5, ZG1 / 4 (pT1 / 4), npt1 / 4 |
Power supply voltage | DC 12 V |
Output voltage | 0~4V |
