Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body

Certification
China Hunan Llano Electronic Technology Co., Ltd certification
I'm Online Chat Now

Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body

Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body
Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body

Large Image :  Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body

Product Details:
Place of Origin: Hunan, China
Brand Name: LLANO
Certification: ISO9001
Model Number: LN-AT12
Payment & Shipping Terms:
Minimum Order Quantity: 100 Sets
Packaging Details: Standard packing for export
Delivery Time: 15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 15000 Piece/Pieces per month

Sequential Fuel Injection Standard CNG Pressure Reducer Regulator Aluminium Body

Description
Product Name: CNG Pressure Regulator Work For: CNG Cars
System: CNG Sequential Injection System Material: Die Cast Aluminium Body
Color: Silver And Blue Quality: 100% Professional Test
Certificate: ISO 9001 Warranty: 1 Year
Highlight:

Standard CNG Pressure Reducer

,

Aluminium CNG Pressure Reducer

,

CNG fuel injection regulator


                  Products Description

LLANO AT12 Standard CNG Pressure Regulator for CNG Sequential Injection

System of Car



AT12 CNG pressure regulator is a 2-stage pressure reducer for traditional CNG sequential

injection systems. It is equipped with a low pressure solenoid valve.



Gas fuel type CNG
Work for CNG sequential injection system
Material Die cast aluminium body
Size 12cm*15cm*15.5cm
Weight 1.8 kg
Max inlet pressure 26 MPa
Outlet pressure adjustable from 160 to 280 kPa
Coil voltage 12 V DC
Coil power 17 W
Inlet Connection M12x1 pipe Ø 6 mm
Outlet connection Swivel fitting Ø 12.5 mm
Coolant liquid connections for rubber pipe Ø 8 mm
MAP connection for rubber pipe Ø 6 mm
Working temperature -40~120 °C
